Featured products - ATEX electrical components
See our selected ATEX-approved electrical components right here
We have gathered our specially selected products within ATEX approved electrical components - developed and selected with a focus on stable, safe and documentable operation in potentially explosive environments.
In ATEX zones, there is no room for compromise. Reliability, correct classification and high quality at all stages are essential!
That's why we offer components and solutions that meet current requirements and standards - and are designed to work reliably under demanding industrial conditions.
We can help both at the component level and in relation to the overall installation, so you get a solution that is technically correct, reliable and future-proof.
Do you need help?
Contact us for sparring, product selection or a specific review of your project.
ATEX switches - ZONE 1/2: ATEX II 2 GD
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 PGE2004-1, GRP, BLACK GREB, ENCLOSURE:160x160x90, Scame
Fiberglass reinforced enclosed switch from the ISOLATORS-EX[GD] series, designed for use in potentially explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle in black
- GRP enclosure 160 x 160 x 90 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2,3 & 4 poles and with auxiliary contacts NO+NC & NO/NC
- Possibility of EMC protection
- Item no.: 55926
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 PEM2004-1, GRP, RED/YELLOW GREB, ENCLOSURE:160x160x90, Scame
Fiberglass reinforced enclosed switch from the ISOLATORS-EX[GD] series, designed for use in potentially explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle red/yellow
- GRP enclosure 160 x 160 x 90 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2,3 & 4 poles and with auxiliary contacts NO+NC & NO/NC
- Possibility of EMC protection
- Item no.: 55925
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 AEM2004-1, RED/YELLOW GREB, ALUKAPSLING:202x232x142, SCAME
Aluminum enclosed switch from the ISOLATORS-EX[GD] series, designed for use in explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle red/yellow
- Enclosure 202 x 232 x 142 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- NO+NC & NO/NC
- Possibility of EMC protection
- Item no.: 56010
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 AGE2004-1, BLACK GRB, ALUKAPSLING:202x232x142, Scame
Aluminum enclosed switch from the ISOLATORS-EX[GD] series, designed for use in explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J) Lockable handle black
- Enclosure 202 x 232 x 142 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2, 3 & 4 poles and with auxiliary contacts NO+NC & NO/NC
- Possibility of EMC protection
- Item no.: 56011
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 SEM2004-1, RED/YELLOW GREB, STAINLESS STEEL ENCLOSURE:141x200x126, Scame
Stainless steel INOX enclosed switch from the ISOLATORS-EX[GD] series, designed for use in potentially explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle red/yellow
- Enclosure 141 x 200 x 126 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2, 3 & 4 poles and with auxiliary contacts NO+NC & NO/NC
- Item no.: 56014
SWITCH, 3/4 POL+ 1NO, 20A, ATEX II 2GD 591 SGE2004-1, BLACK GRB, STAINLESS STEEL ENCLOSURE:141x200x126, Scame
Stainless steel INOX enclosed switch from the ISOLATORS-EX[GD] series, designed for use in potentially explosive environments.
Advantages:
- 20 A, 3/4-pin + 1NO, 690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle black
- Enclosure 141 x 200 x 126 mm, 2x M25 cable entries
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2, 3 & 4 poles and with auxiliary contacts NO+NC & NO/NC
- Item no.: 56013
ATEX switches - ZONE 21/22 - ATEX II 2D
SWITCH, 3POL +1NO/1NC, 25A, ATEX ZONE 22/21 KG20 T203/NL-EXRA KNBOX (ATEX), Kraus & Naimer
Thermoplastic ATEX approved switch for zone 21/22 (Dust EX, Dust group D).
Advantages:
- 25 A, 3-pin + 1 NO/NC, 7.5 kW, 3x400V, AC-23B
- ATEX II 2 D Ex tb IIIC Db IP66, impact resistance 7 J
- Incl. 2x M25 + 1x M20 blind plug screw connection
- Enclosure 115 x 190 x 128 mm
- Available in 25A, 32A, 40A, and 63A
- Available with 3, 4 and 6 poles and auxiliary contact NO/NC
- EMC versions available
- Item no.: 53053
SWITCH, 3 POL, 20A, ATEX II 2D (21&22) 590 XHEM2003, RED/YELLOW GREB, IP65, ALU BOX:105x150x82, Scame
Aluminum DIE-CAST enclosed ATEX approved switch for zone 21/22 (Dust EX, Dust group D).
Advantages:
- 20 A, 3-pole, -25-60 °C
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle red/yellow
- Enclosure 105 x 150 x 82 mm, 2x M25 cable entries + 1 x M20
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2, 3 & 4 poles and with auxiliary contacts 1NO + 1NC & NO/NC
- Item no.: 56016
SWITCH, 3 POL, 20A, ATEX II 2D (21&22) 590 XHGE2003, BLACK GREB, IP65, ALUKAPSLING:105x150x82, Scame
Aluminum DIE-CAST enclosed ATEX approved switch for zone 21/22 (Dust EX, Dust group D).
Advantages:
- 20 A, 3-pole, -25-60 °C
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and IK07 impact resistance (7 J). Lockable handle black
- Enclosure 105 x 150 x 82 mm, 2x M25 cable entries + 1 x M20
- Available in 20A, 25A, 32A, 40A, and 63A
- Available in 2, 3 & 4 poles and with auxiliary contacts 1NO + 1NC & NO/NC
- Item no.: 56015
ATEX terminal boxes/junction boxes
ATEX-TERMINAL BOXES, 10x2,5 MM TERMINALS, 12A ZENITH P, BLACK, 690V, IP66, 3050W, II 2GD, Scame
Robust terminal box/junction box in the ZENITH-P series for ATEX ZONE II 2GD.
Advantages:
- 12 A, 690 V. 3050 W
- ATEX II 2 GD Ex eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK0 protection
- 10 x 2.5 mm² CAGE TERMINAL
- Working temperature -30 °C to +40 °C
- 4 x M20 cable entries, Enclosure 110 x 75 x 55 mm
- Item no.: 55979
ATEX-TERMINAL BOXES, 4x WDU, 4,0MM TERMINALS, 24A ZENITH P, BLACK, 690V, IP66, 2170W, II 2GD, Scame
Robust terminal box/junction box in the ZENITH-P series for ATEX ZONE II 2GD.
Advantages:
- 24 A, 690 V. 2170 W
- ATEX II 2 GD Ex eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- 4 x WDU 4.0 mm²
- Working temperature -30 °C to +40 °C
- 4 x M20 cable entries. Enclosure 122 x 120 x 90 mm
- Item no.: 55978
ATEX-TERMINAL BOXES, 8x4,0 MM WDU TERMINALS, 20A ZENITH P, BLACK, 550V, IP66, 3010W, II 2GD, Scame
Robust terminal box/junction box in the ZENITH-P series for ATEX ZONE II 2GD.
Advantages:
- 20 A, 550 V AC. 3010 W
- ATEX II 2 GD Ex eb IIC T6 Gb/Ex tb IIIC T80 °C Db.
- IP66, IK07 protection
- 8 x WDU 4.0 mm² (BRIDGED 2/2)
- Working temperature -30 °C to +40 °C
- 4 x M20 cable entries. Enclosure 122 x 120 x 90 mm
- Item no.: 55980
ATEX control boxes
ATEX CONTROL BOX, 1 E-STOP ROTARY VALVE - 2NC COMPACT-EX 16A, 250V, 1660W, IP66, II 2GD, THPLAST, Scame
Thermoplastic emergency stop box from the COMPACT-EX[GD] series with rotating emergency stop function.
Advantages:
- 16 A, 250 V AC, AC12.1660 W
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- Working temperature -35 °C to +40 °C
- 1 x M20 cable entry. Enclosure 95 x 95 x 80mm
- Item no.: 55953
ATEX CONTROL BOX, 1 E-STOP PRESSURE VALVE - 2NC COMPACT-EX 16A, 250V, 1660W, IP66, II 2GD, THPLAST, Scame
Thermoplastic emergency stop box from the COMPACT-EX[GD] series with pull-to-release.
Advantages:
- 16 A, 250 V AC, AC12.1660 W
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- Working temperature -35 °C to +40 °C
- 1 x M20 cable entry. Enclosure 95 x 95 x 80 mm
- Item no.: 55952
ATEX CONTROL BOXES, STOP - START, 2 BUTTONS - 1NO/NC COMPACT-EX 16A, 250V, 1660W, IP66, II 2GD, THPLAST, Scame
Thermal load start/stop box from the COMPACT-EX[GD] series.
Advantages:
- 16 A, 250 V AC, AC12. 1660 W
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db IP66
- IP66, IK07 protection
- Working temperature -35 °C to +40 °C
- 1 x M20 cable entry. Enclosure 95 x 95 x 80 mm
- Item no.: 55955
ATEX wall outlet
ATEX distribution cabinet 32 A, 579.EX20-105, Scame
Surface-mounted distribution cabinet from the ADVANCE-GRP series for dust and gas areas.
Advantages:
- 32 A, 400 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 tightness and operating temperature: -25 °C to +60 °C
- GRP enclosure, self-extinguishing UL94 V0
ATEX socket 125 A 3P+E, 504.125867, Scame
Heavy-duty socket with mechanical interlock for use in harsh EX environments.
Advantages:
- 125 A, 3P+E, 600-690 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, made of glass fiber reinforced polyester (GRP)
- Option for padlock locking in OFF position
ATEX junction box 160x160x90 mm, 644.0585-168710, Scame
Large surface-mounted junction box for demanding industrial environments.
Advantages:
- 20 A, 550 V AC
- ATEX II 2 GD Ex eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 and IK07 enclosure rating
- Thermoset, black housing, 4 x M25 cable entries
CEE plug ATEX
CEE-CONNECTOR, ATEX, MALE CONNECTOR, SHEATH CLAMP, EX II 2GD 16A 2P+ E+ 6H 200-250V (BLUE) IP66, 60Hz 50Hz, Scame
Compact plug from the OPTIMA-EX[GD] series, designed for use in explosive environments (gas and dust).
Advantages:
- 16 A, 2P+E, 200-250 V AC, 6H
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- Operating temperature -50 °C to +60 °C
- Available in 16A, 32A, 63A and 125A in 3, 4 and 5-pin versions
- Item no.: 55948
CEE-CONNECTOR, ATEX, MALE CONNECTOR, SHEATH CLAMP, EX II 2GD 32A 2P+ E+ 6H 200-250V (BLUE) IP66, 60Hz 50Hz, Scame
Compact plug from the OPTIMA-EX[GD] series, designed for use in explosive environments (gas and dust).
Advantages:
- 32 A, 2P+E, 200-250 V AC, 6H
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- Operating temperature -50 °C to +60 °C
- Available in 16A, 32A, 63A and 125A in 3, 4 and 5-pin versions
- Item no.: 55949
CEE-CONNECTOR, ATEX, MALE CONNECTOR, SHEATH CLAMP, EX II 2GD 16A 3P+ N+ E+ 6H 346-415V (RED) IP66, 60Hz 50Hz, Scame
Compact plug from the OPTIMA-EX[GD] series, designed for use in explosive environments (gas and dust).
Advantages:
- 16 A, 3P+N+E, 346-415 V AC, 6H
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK07 protection
- Operating temperature -50 °C to +60 °C
- Available in 16A, 32A, 63A and 125A in 3, 4 and 5-pin versions
- Item no.: 55950
ATEX rocker switches
SWITCH, 16AX, 2P+ NO+ NO, EX II 2GD VIPPEKONTAKT, TERMOPLAST, IP66, 250V, 1xM20, IK7J, Scame
Thermoplastic enclosed toggle switch from the ROCKER-EX (GD) series.
Advantages:
- 16 AX, 250 V AC. 2 pole
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK7J protection
- 1 x M20 cable entry
- Operating temperature -35 °C to +60 °C
- Option for AISI 316L steel screws
- Item no.: 55972
SWITCH, 16AX, 2P+ NO+ NO, EX II 2GD VIPPEKONTAKT, TERMOPLAST, IP66, 250V, 2xM20, IK7J, Scame
Thermoplastic enclosed toggle switch from the ROCKER-EX (GD) series.
Advantages:
- 16 AX, 250 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK7J protection
- 2 x M20 cable entries
- Operating temperature -35 °C to +60 °C
- Option for AISI 316L steel screws
- Item no.: 55973
SWITCH, 16AX, 2P+ NO+ NO, EX II 2GD VIPPEKONTAKT, TERMOPLAST, IP66, 250V 1xM20+2xM20, Scame
Thermoplastic enclosed toggle switch from the ROCKER-EX (GD) series.
Advantages:
- 16 AX, 250 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66, IK7J protection
- 2 x M20 cable entries
- Operating temperature -35 °C to +60 °C
- Option for AISI 316L steel screws
- Item no.: 55974
ATEX enclosures
ZENITH P-series
Empty enclosures in thermoset GRP material for zones 1-2 (gas) and 21-22 (dust).
ZENITH-S series
Empty stainless steel enclosures for zones 1-2 (gas) and 21-22 (dust).
ALUBOX-EX series for II 3GD
Empty die-cast aluminum enclosures for zones 2-22 (dust).
ATEX extension cables
ATEX extension cable 25 m, 16 A, 3P+E, 759.1636-25, Scame
Extension cable for hazardous areas in the OPTIMA-EX[GD] series.
Advantages:
- 16 A, 3P+E, 380-415 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 protection
- 4 x 2.5 mm² cable, 25 m length
ATEX extension cable 25 m 16 A 3P+N+E, 759.1637-25, Scame
Flexible extension cable from the OPTIMA-EX[GD] series for use in hazardous environments in zone 1/21.
Advantages:
- 16 A, 3P+N+E, 346-415 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 protection, cable section 5 x 2.5 mm²
- Black thermoplastic cable, length 25 m, 6h position
ATEX extension cable 5 m, 759.3233-05, Scame
Short extension cable for use in zone 1/21 with high mechanical robustness.
Advantages:
- 32 A, 2P+E, 200-250 V AC
- ATEX II 2 GD Ex db eb IIC T6 Gb/Ex tb IIIC T80 °C Db
- IP66 protection
- 3 x 6 mm² cable, 5 m length
ATEX screw connections
ATEX EMC cable gland M50, 805.RAS505050ES, Scame
Stainless steel cable gland with EMC protection and double sealing.
Advantages:
- ATEX II 2 GD Ex tb IIIC Db IP66
- IP66/IP68 tightness, AISI 316L stainless steel
- EPDM gasket, cable diameter 24-36 mm
- Temperature range: -40 °C to +100 °C
ATEX EMC cable gland M90, 805.RAS9190EN, Scame
Nickel-plated brass cable gland with EMC connection.
Advantages:
- ATEX II 2 GD Ex tb IIIC Db IP66
- IP66/IP68 tightness, EMC compliant
- Cable diameter 54-68 mm
- Temperature range: -40 °C to +100 °C
ATEX magnifier adapter M16/M12, 805.EX5016K, Scame
Adapter for thread transition between M12 and M16 in potentially explosive environments.
Advantages:
- ATEX II 2 GD Ex eb IIC/Ex tb IIIC
- IP66/IP68 tightness with neoprene gasket
- Thermoplastic material, black
- Temperature range: -35 °C to +95 °C
ATEX solenoid valves
ATEX magnet, FMME, Magnet-Schultz
Explosion-proof magnet for hydraulic and mechanical applications.
Advantages:
- ATEX II 2 G Ex eb mb IIC T6/T4 Gb/II 2 D Ex tb IIIC T80°C/T130°C Db
- IP65/IP67 depending on design
- 5-230 V DC, S1 100 % ED
- Temperature range: -30 °C to +60 °C
ATEX firing pin locking unit, FMME + FSTX, Magnet-Schultz
Electromagnetic shootbolt for locking machines in zone 1/21.
Advantages:
- ATEX II 2 G Ex eb mb IIC T6/T4 Gb/II 2 D Ex tb IIIC T80°C/T130°C Db
- IP65/IP67 protection
- 24 V DC, 100 % ED (S1)
- High locking force and linear stroke characteristics
ATEX solenoid (DC), GTCE, Magnet-Schultz
Energy-efficient DC solenoid for hazardous areas in gas and dust zones.
Advantages:
- ATEX II 2 G Ex eb mb IIC T4/T5 Gb/II 2 D Ex tb IIIC T95°C/T130°C Db
- IP65 electrical/IP54 mechanical part
- 24 V DC, S1 100 %, sizes 50/100/140 mm
- Long lifespan and high impact force
What does ATEX mean?
Learn about ATEX regulations, zoning and certification requirements for equipment in hazardous areas.
A practical introduction to what ATEX means in operation and installation.
ATEX-approved products for industrial IT
Robust ATEX-approved solutions for industrial networking and data infrastructure.
We stock switches, routers and panel PCs for stable operation and secure communication in classified zones.
